Bremen B2

Music streaming services are gradually becoming important music sources. Many music lovers actively seek out their favorite brands of Bookshelf Powered/Active Speakers or Bluetooth speakers to have a better sound quality. However, even with the favorite speakers, there are still limitations in sound quality from the connected computer, mobile phone, or tablet.

Silent Angel’s Bremen B2 streamer is an independent player system with numerous built-in capabilities. It can replace mobile phones or computers as a streaming player. It can operate independently and play stably without other devices or turning on a computer. The B2 has been specially designed to the highest standard for noise reduction and stable sound quality. Encased in high quality metal, the B2 is reinforced by a high-quality power supply and supports a variety of digital and analog audio output interfaces.

Benefits of the Bremen B2 Include:

01.

Easy to Set up and Stream

The B2 is controlled via the control panel located on the device or the mobile app, allowing streaming to be easily accessible.

02.

Always Connected. No Interruption

While playing music, the B2 will not be interrupted by other devices, such as an incoming phone call or a notification sound on a tablet.

03.

Premium Sound Quality With Music Details

Music stability is not affected by the computer’s performance and system loading, but will be served by the B2 system.

04.

Pair With Any Grade Systems

Thanks to the built-in DAC, enjoy enhanced streaming sound quality.

The Bremen B2 streamer pairs perfectly with higher-end HiFi systems. It is also the companion for the mid to entry options.

  1. It works well with a variety of well-known brand speakers, freshening your options for a premium yet affordable sound system. Some brands (Bookshelf powered speaker) that the Bremen B2 work well with but is not limited to:
  • Audioengine
  • Bose
  • Edifier
  • ELAC
  • Genelec
  • JBL
  • Klipsch
  • Neumann
  1. B2 works well with lots of well-known Amp through the analog audio output, and can present the potential of the sound quality while serving the high-res streaming music.
  1. B2 is also the ideal streamer choice for those high-end HiFi system setup, delivering the surprisingly pleasant audio quality.

Highlights

  • Deploy by either wired Ethernet or WiFi. Flexibly place it anywhere.
  • Connect and maximize well-known brands’ active/powered speakers.
  • Can simply connect to any stereo amplifier, DAC or speaker(s).
  • Manage and play by mobile app, VitOS Lite.
  • Supports Bluetooth 5.0. Conveniently play music from your smartphone or tablet.

Versatile Applications

Supported applications include Tidal Connect, Qobuz, Spotify Connect, Amazon Music, Napster, Tune-in radio, Sound Machine, and music files from network-shared storage via DLNA.

Mobile App, VitOS Lite

Easily browse, manage, stream and enjoy your favorite music and streaming services.

Quality Hardware System

The B2 is born to pursue HiFi-level audio performance without any compromise.

  • Elegant metal enclosure
  • 2-core 1.2GHz ARM Cortex-A7 CPU
  • Advanced circuitry with high quality components
  • Highly permeable EMI absorber to reduce electrical interference
  • Gold plated audio output ports (RCA L/R, 6.35mm headphone jack, and Coaxial & AES/EBU)
  • Digital output: AES/EBU, I2S, Coaxial for external DAC
  • Analog output: RCA (L+R) for any amplifier or active speaker(s)
  • WiFi 802.11 ac/b/g/n 2.4GHz & 5GHz (client mode) for ease of deployment. Internal antenna x5

Enjoy by Connecting Headphones

The B2 integrates a HiFi headphone Amp with a 6.35mm headphone jack on the front–delivering quality music with no PC involved.

Connect the B2 to Powered Speakers

The B2 employs a built-in DAC with volume control, which can then be connected to speakers with no PC required.

Obtain More Audio Sources For HiFi Systems

  • Connect to DAC or any stereo amplifier
  • Play high-resolution streaming services and Internet radios
  • Play music files from network shared storage via DLNA

Further Upgrade - The Combo Setup

  • Vibration Suppression
    Minimize vibration and reduce noise by using S28 stainless steel stands.
  • Network Purifier
    Connect B2’s wired Ethernet port to the N8 switch and create an isolated audio network. (*Related models: N8, N8 Pro, and N16-LPS)

Music Streamer/ Transporter - Munich and Bremen Series

M1M1TB2B1B1T
Productproduct-icon-m1
Network Music Streamer
product-icon-m1t
Network Music Transporter
product-icon-b2
Network Music Streamer For HiFi Entry
product-icon-b1
Network Music Streamer For HiFi Entry
product-icon-b1t
Network Music Transporter For HiFi Entry
Applications

  • Hi-res music streaming services

  • Roon Ready Player

  • Local or LAN music via SMB (NAS), DLNA

  • Digital & Analog Audio Outputs

  • Play DSD files

  • MQA-supported

  • Headphone


  • Hi-res music streaming services

  • Roon Ready Player

  • Local or LAN music via SMB (NAS), DLNA

  • Digital Audio Outputs (to DAC)

  • Play DSD files

  • MQA-supported


  • Music streaming services

  • Digital & Analog Audio Outputs

  • DLNA renderer (player)

  • Headphone


  • Music streaming services

  • Digital & Analog Audio Outputs

  • DLNA renderer (player)

  • Headphone


  • Music streaming services

  • Digital Audio Output (to DAC)

  • DLNA renderer (player)

MQAN/AN/AN/A
PCMUSB: 768kHz
AES/EBU: 384kHz
USB: 768kHz
AES/EBU: 384kHz
up to 192kHzup to 192kHzup to 192kHz
DSDUSB: DSD 256
AES/EBU: DSD 128
USB: DSD 256
AES/EBU: DSD 128
N/AN/AN/A
Streaming MusicAmazon Music: 96KHz
TIDAL: 192kHz
TIDAL Master(MQA)
Qobuz: 192kHz
HIGHRESAUDIO: 192kHz
Amazon Music: 96KHz
TIDAL: 192kHz
TIDAL Master(MQA)
Qobuz: 192kHz
HIGHRESAUDIO: 192kHz
Amazon Music: 44.1KHz
TIDAL: TIDAL HiFi
Qobuz: 192kHz
Amazon Music: 44.1KHz
TIDAL: TIDAL HiFi
Qobuz: 192kHz
Amazon Music: 44.1KHz
TIDAL: TIDAL HiFi
Qobuz: 192kHz
Operating SystemVitOSVitOSVitOS LiteVitOS LiteVitOS Lite
CPUDual Cortex-72 18GHz
Qual Cortex-A53 1.4GHz
Dual Cortex-72 18GHz
Qual Cortex-A53 1.4GHz
2 Cores 1.2GHz
ARM Cortex-A72
2 Cores 1.2GHz
ARM Cortex-A72
2 Cores 1.2GHz
ARM Cortex-A72
DRAM4GB4GB128 MB128 MB128 MB
Flash32 GB High Speed32 GB High Speed128 MB128 MB128 MB
LANGigabit Ethernet
(max 1000Mbps)
Gigabit Ethernet
(max 1000Mbps)
Fast Ethernet
(max 100Mbps)
Fast Ethernet
(max 100Mbps)
Fast Ethernet
(max 100Mbps)
BlueToothN/AN/ABlueTooth 5.0 with EDR and BLEBlueTooth 5.0 with EDR and BLEBlueTooth 5.0 with EDR and BLE
Wi-FiN/AN/A802.11 a/b/g/n/ac
2.4GHz, 5GHz
802.11 a/b/g/n/ac
2.4GHz, 5GHz
802.11 a/b/g/n/ac
2.4GHz, 5GHz
Wi-Fi AntennaN/AN/AInternal AntennaDirectional AntennaDirectional Antenna
Digital Audio OutputsAES/EBU
Coaxial
I2S
USB Audio
AES/EBU
Coaxial
I2S
USB Audio
AES/EBU
Coaxial
I2S
AES/EBU
Coaxial
I2S
AES/EBU
Coaxial
I2S
Analog Audio OutputsRCA L+R
6.35mm Headphone Jack
N/ARCA L+R
6.35mm Headphone Jack
RCA L+R
6.35mm Headphone Jack
N/A
Learn more Learn more Learn more Learn more Learn more

Product Specification

Available ColorBlack
Power Input(AC) 115-230V
Power Consumption10W at max
Headphone Jack6.35 mm headphone jack
33 Ohm:
- 1mW, THD+N : 0.0035%
- MAX : 375mW THD+N : 0.002%

590 Ohm:
- Max : 27.5mW, THD+N : 0.0015%
Digital OutputsAES/EBU port x 1
I2S port x 1
Coxial port x 1
- Supports up to PCM 192KHz
Analog OutputRCA (L+R)
- 2Vrms THD+N : 0.00134 / 0.00164%
- Frequency response : 20Hz ~20KHz+- 0.5dB
- SNR : 108dB
M-IOM-IO port x 1 for peripheral access
Ethernet100Mbps RJ45 x 1
Wireless ConnectionWi-Fi 802.11 a/b/g/n 2.4GHz
Bluetooth 4.2
Front Panel ButtonPrevious Track, Pause / Play, Next Track, Volume Increase, Volume Decrease
System Status IndicatorFast blinking: system is booting
Green light: the network is connected (WiFi or Ethernet)
Slow blinking: the network is disconnected
Blue light: bluetooth is connected
Red light: mute
- Press and hold the Play button for 3 seconds to turn the indicator light ON or OFF
TemperatureOperating: 32 ~ 86 °F
Storage: -4 ~ 158 °F
HumidityOperating: 10% ~ 90% RH (non-condensing)
Storage: 5% ~ 95% RH (non-condensing)
Dimensions12.13(W) inch x 1.89(H) inch x 6.78(D) inch
308(W) mm x 48(H) mm x 172(D) mm
Weight2.21 lbs / 1.0 kg
Document DownloadB2 Quick Start Guide
