Music Server Board Set
The main components of a music server include the motherboard, CPU, memory, storage device, audio interface, operating system, and software application. By selecting the appropriate components and configuration, you can ensure the stability, performance, and reliability of the music server. You can build a powerful and efficient music server to meet your music storage and playback needs. Through the USB Audio output, it can be used as a player.
| Processor | Intel processor J6413, quad-core, 1.8GHz, turbo frequency 3.0GHz, 10nm process |
|---|---|
| Operating System | VitOS by Silent Angel |
| Memory | DDR4 SODIMMX2, maximumsupport 32GB |
| M.2 storage | M.2×1 M.2 key M 2280, support NVME, SATA |
| M.2 WIFI | M.2 x2 M.2 PCIE supports WiFi-5, WIFI-6 (AX200), does not support CNVI |
| HDMI | HDMI1.4 (for engineering) |
| Ethernet | 10/100/1000M network support*2 |
| USB port | USB3.1*2 (can be used to connect external storage devices, high current devices require external power hub) |
| Type-c | Type-c x1 USB2.0 data, video, no PD |
| SATA | SATA x1, power supply x1 |
| Power | 12V / 3A (specification 5.5mm x 2.5mm, port input + 12V) |
| Clock | 25MHz clock access port (BNC interface, 50 ohm impedance) |
