Music Player Module C01

Music Player Module

A low-power, high-performance application processor chip widely used in mobile devices, embedded systems, and other low-power and high-performance demand scenarios. A CPU ARM with six processing cores, capable of supporting WIFI, Bluetooth, USB 3.0 * 2, USB 2.0, USB Audio * 1, and 40PIN expansion interfaces.

Contact Us

Specification

Additional information

Processor

Dual core ARM®Cortex-A72@1.8GHz
Quad core ARM®Cortex-A53@1.4GHz
Graphics Processing Unit

Arm Mali™ T860MP4 GPU，support
– OpenGL®ES 1.1 / 2.0 / 3.0 / 3.1 / 3.2
– Vulkan® 1.0
– OpenCL® 1.1 / 1.2
– DirectX® 11.1
Video Processor

H. 265/VP9 (HEVC) hardware decoding (up to 4Kp60)
H. 264 hardware decoding (up to 1080p60)
Power Management

RK808 PMU Power management unit
Memory

Dual channel LPDDR4 4GB
Storage

1x M.2 M Key supports NVMe SSDs
1 TF card slot
VitOS System Software

1. Streaming music includes: Internet Radio, Roon Ready, DLNA Renderer, QPlay,TIDAL Connect, TuneIn, Spotify Connect, Roon Ready, embedded TIDAL, embedded Qobuz, embedded Amazon Music HD
(Certification is applied by the client and the certification party, and we take over the testing account to cooperate with the certification)
2. Local music includes: network storage, USB storage, my favorites, my playlists, albums,keyword search: track, album, artist
3. Settings include: audio output settings, language, more settings, about
Dimension

56(W) mm x 85(H)mm x 1.6(D)mm
